Branths rust protection red lead free 0.75 liter container

SKU: 75.415135
Category: Branth's red lead free
Manufacturers: Branth Chemie A.V. KG

European ADR hazard sign:

1263

Universal red lead

£ 14,96

£ 2,00 per 100 ml

incl. 0% VAT , plus

Delivery time: 2 - 6 Workdays Other countries

Description
Question about item

BRANTH's lead-free rust protection red lead can be used universally as a primer and filler.

Color: orange, matt.

If you want to prime and paint immediately in RAL colors, then BRANTHO -KORRUX "3in1" better suited.

Lead-free red lead does not contain zinc, chromate or xylene!

Red lead is characterized by short drying times: at 20º C / 65% rel. Humidity dust-dry after approx. 30 minutes, touch-proof after approx. 90 minutes and completely dry after 24 hours. Please do not force-dry.

Yield:
Calculated approx. 9.3 m² for 60 µm or 18.6 m² for 30 µm. However, one coat enables higher layer thicknesses, so the practical consumption is approx. 0.15 liters per m² (750 ml is sufficient for approx. 5 m², 1 liter for approx. 6.6 m²).

BRANTH's amount of rust protection can be applied to 1-component and 2-component leveling compounds. The suitability of the leveling compounds from third-party manufacturers must always be checked by the user himself. Reworking with 1-component leveling compounds is possible from the following day. The overworking with 2-component leveling compounds should take place after 1 to 2 weeks at the earliest, because the rust protection red lead is dissolved, which ensures a good bond, but requires careful work. Brantho-Korrux "2-Kompo" is better suited for quick reworking with 2-component fillers.

Suitable topcoats: other colors from BRANTH, suitable paints from third-party manufacturers.

Advantages of the Lead-free corrosion protection red lead:

The rust protection paint is very creamy and just as easy to paint as the well-known red lead.
BRANTH's red lead is a good substitute for the highly toxic red lead, which is no longer allowed to be sold to end users br /> BRANTH's rust protection red lead is a high-quality, matt, one-component coating (color orange) with quick drying and high corrosion protection. It is ideally suited as a primer and filler at the same time, but can also be used on surfaces that have only been rustproofed by hand.

BRANTH's rust protection red lead is free from heavy metals and aromatics and an emission-reduced product for use in environmentally friendly areas.

Areas of application:

Among other things for corrosion protection on parts and constructions made of iron and steel in rural, urban, industrial and marine atmospheres. For new and overhaul coatings. As an active anti-corrosive primer coat for top coats based on alkyd, acrylic, PVC, polyester, cyclo-rubber, bitumen, PU etc. For rust protection on vehicles, machines, vehicle components, transport racks, ships, boats.

Technical data of the Corrosion protection red lead:

BRANTH' s rust protection red lead is a PVC-free binder combination made from natural and synthetic resins with environmentally friendly, yet highly effective corrosion protection pigments.

Delivery viscosity:

200 sec. / DIN 4 mm

Thinner:

BRANTH's combination thinner (short drying time), BRANTH's special thinner (delayed drying). White spirit, petroleum ether, etc. are not suitable.

Solid content:

approx. 75% (weight) / 56% (volume)

Processing instructions:

Suitable paint carriers are iron and steel structures that are free of rust, rolled skin and loose layers of paint.
Can be used on surface rust, surfaces that have been de-rusted by hand and damp-blasted surfaces.
Very good adhesion on intact, not loose old coatings. The substrate must be clean, dry and stable.
Application by brushing and rolling:
undiluted in delivery form or with minimal addition of thinner.

Conventional spraying (compressed air / spray gun): < / h3>

for nozzles of 1.2 to 1.8 mm and 4 to 5 bar approx. 8 to 10% thinner should be added.
Airless spraying:
at least 180 bar, with Nozzle sizes from 0.3 to 0.6 mm and spray angles from 40 to 80 degrees should be added approx. 3 to 5% thinner.

Ideal processing temperature:

18 to 25° C
Possible processing temperature: minus 10 to plus 30° C

Drying:

at approx. 20° C and 65% rel. Humidity:
Dust dry after approx. 30 minutes.
Dry to the touch after approx. 90 minutes.
Thoroughly dry after approx. one day
Do not force-dry. The exact drying times depend on the temperature and layer thickness.

Filling:

According to the manufacturer's instructions, BRANTH's red lead can be applied to all 1-component and 2-component leveling compounds known to the manufacturer. Reworking with 1-component leveling compounds is possible from the following day. 2-component leveling compounds should be applied after 1 to 2 weeks at the earliest. In the case of 2-component leveling compounds, the red lead is dissolved, which ensures a good bond, but requires careful work. BRANTHO-KORRUX 2-Kompo is more suitable for 2-component filler and quick reworking.

Can be painted over:

BRANTH's anti-rust red lead can be used at any time without sanding with BRANTHO-KORRUX "3in1" or BRANTH' s Robust Lack can be painted over.
With other 1-component intermediate or top coats, BRANTH' s anti-rust red lead can be painted over after 1 to 2 hours without sanding. In the case of 2-component intermediate and top coats from other manufacturers, BRANTH' s rust protection red lead can be painted over after one day or later without sanding.

GISBAU product code: M-GP02
